Specifications
| LENGTH | 8" x 1/2" x 1"<br>8" x 3/4" x 1"<br>12" x 3/4" x 1"<br>12" x 1" x 2" |
|---|---|
| Weight (lb) | 30 |
The P4W-SET-B from Suburban Tool is a 4-way ground precision steel parallel set containing four matched pairs, in sizes 8" x 1/2" x 1", 8" x 3/4" x 1", 12" x 3/4" x 1" and 12" x 1" x 2".
Made of alloy steel hardened to Rc 58-60 and ground on four sides, these parallels are held to size within 0.00025", so they can be used individually or mixed across sizes for workholding where extra precision is required.
- Four matched pairs ground on four sides for flexibility
- Held to size within 0.00025" on four sides
- Adjacent sides square within 0.0005" per inch
- Opposite sides parallel within 0.0001" per 6 inches
- Alloy steel hardened to Rc 58-60 for durability
- Furnished in a wooden holder marked with sizes
- Made in the USA by Suburban Tool
- Each set includes four pairs of parallels in the sizes shown.
- Pairs are matched in size on the width and height to a tolerance of ±0.0002" on 6", 8" & 12" lengths and ±0.0003" for longer lengths.
- Total parallelism, straightness over the full length is 0.0001" on 6" & 8" lengths, 0.0002" on 12" lengths & 0.0003" on longer lengths.
- Adjacent ground sides are square with each other within 0.0004", except the 1/4" wide models, which are square within 0.0005".
Specifications
| LENGTH | 8" x 1/2" x 1"<br>8" x 3/4" x 1"<br>12" x 3/4" x 1"<br>12" x 1" x 2" |
|---|---|
| Weight (lb) | 30 |
The P4W-SET-B from Suburban Tool is a 4-way ground precision steel parallel set containing four matched pairs, in sizes 8" x 1/2" x 1", 8" x 3/4" x 1", 12" x 3/4" x 1" and 12" x 1" x 2".
Made of alloy steel hardened to Rc 58-60 and ground on four sides, these parallels are held to size within 0.00025", so they can be used individually or mixed across sizes for workholding where extra precision is required.
- Four matched pairs ground on four sides for flexibility
- Held to size within 0.00025" on four sides
- Adjacent sides square within 0.0005" per inch
- Opposite sides parallel within 0.0001" per 6 inches
- Alloy steel hardened to Rc 58-60 for durability
- Furnished in a wooden holder marked with sizes
- Made in the USA by Suburban Tool
- Each set includes four pairs of parallels in the sizes shown.
- Pairs are matched in size on the width and height to a tolerance of ±0.0002" on 6", 8" & 12" lengths and ±0.0003" for longer lengths.
- Total parallelism, straightness over the full length is 0.0001" on 6" & 8" lengths, 0.0002" on 12" lengths & 0.0003" on longer lengths.
- Adjacent ground sides are square with each other within 0.0004", except the 1/4" wide models, which are square within 0.0005".
- Regular price
- $3,145.00
